CORESENSE D7.4 — Inspection Testbed Implementation

🧭

Overview

What this deliverable implements and why it matters

The Core Idea

D7.4 implements the CORESENSE Collective Awareness Architecture (defined in D7.3) inside the Aerostack2 drone framework. A fleet of drones can now discover each other at runtime, distribute inspection targets via distributed auctions, and safely negotiate shared flight corridors — all without a central coordinator, and without modifying any existing Aerostack2 component.

as2_ca

📡

CA Middleware

CA Gateway node + CA Client library. Peer discovery, modelet routing, and behavior registration. The inter-agent communication backbone.

as2_core · as2_python_api

🧠

Knowledge Base Interface

C++ KBInterface and Python KBMonitorNode bridge behaviors and mission scripts to the CORESENSE knowledge_core RDF store.

as2_behaviors

🏷️

Auction Behavior

Implements the auctions collective model. Drones bid with distance costs; greedy-sequential convergence assigns targets identically on every drone.

as2_behaviors

🛡️

Collision Avoidance

Implements the consensus collective model. Pairwise path-lock arbitrates corridor access before motion begins.

Aerostack2 Behaviors as CORESENSE Cognitive Modules

📐

Models

The behavior class defines the mandatory coordination protocol — what must happen and in what order.

⚙️

Engines

Loadable plugins provide the how. Swapping greedy_sequential or pairwise_path_lock changes the algorithm, not the protocol.

📦

Modelets

Typed ROS 2 messages — Bid, CAPathLockRequest, CAPathLockGrant — exchanged between cognitive modules.

📡

Collective Awareness Middleware

Package as2_ca — the inter-agent communication backbone

Participation Contract

Any drone that (1) deploys a CA Gateway node, (2) uses the CA Client API, and (3) exchanges only as2_msgs vocabulary is immediately interoperable with every conforming peer — the gateway enforces all three obligations at the transport, registry, and semantic levels.

A 1-second timer scans the live ROS 2 topic graph for topics ending in /gateway_in. Newly found topics become peer publishers; publishers whose topics disappear are pruned. No fleet-size configuration needed — satisfies IT-FR-028 (Swarm Size Awareness).

void CA_Gateway::check_peers()
{
  const std::string suffix = "/" + INCOMING_TOPIC_SUFFIX;
  auto topics = this->get_topic_names_and_types();
  for (auto & [name, types] : topics) {
    if (name ends with suffix && name != own_incoming_topic)
      if (not already known) create publisher to name;
  }
  prune peers with no subscribers;
}

Header-only (as2_ca/ca_gateway_client.hpp). Two operations mirror native ROS 2 pub-sub but work fleet-wide:

register_module<T> — like create_subscription but covers all current and future peers; delivers sender namespace as second argument
forward_IA_msg<T> — like publish but addressed by drone namespace names, not topic paths

// Register handler — covers ALL peers automatically:
client_.register_module<as2_msgs::msg::Bid>(
  "bid", "auction_behavior",
  [this](const as2_msgs::msg::Bid & msg, const std::string & sender) {
    auction_plugin_->on_bid_received(msg, sender);
  });

// Forward to named peers — no topic paths needed:
client_.forward_IA_msg<as2_msgs::msg::Bid>(bid, "bid", bidders_);

Modelet Vocabulary (`as2_msgs`)

Auction

StartAuction

Sent by the auctioneer to open a round. Carries the list of items and the set of bidder namespaces.

Auction

Bid

Core auction modelet. Parallel arrays of item name and corresponding cost amounts, one per item.

Path Lock

CAPathLockRequest

Requests corridor access. Contains requester_id, monotonic req_id, and the full path[] as a polyline.

Path Lock

CAPathLockGrant

Peer acknowledgement of a lock. Contains granter_id, requester_id, and the matching req_id.

Path Lock

CAPathLockRelease

Broadcast when a corridor is freed. All peers flush their deferred_ queue for the releasing drone.

Transport

InterAgentMessage

Envelope for any modelet on the inter-drone channel: sender namespace, type string, raw data[].

CA Gateway vs. Raw ROS 2 DDS

Dimension	CA Gateway	Raw ROS 2 DDS
Discovery overhead	Peer registry resolved once at send time	Graph queried per message type at runtime
Naming coupling	Typed registry — no topic names in behavior code	Per-type topic names hard-coded
Transport flexibility	Backend swappable (DDS, Zenoh, MQTT)	Tied to DDS
Fleet reconfiguration	Handled automatically	Explicit pub/sub rewiring required

🧠

Knowledge Base Interface

Connecting behaviors to the CORESENSE knowledge_core RDF triple store

C++ · as2_core

KBInterface

Synchronous-style API for asserting, retracting, and querying RDF facts. A dedicated background thread lets query_kb block safely from inside ROS 2 callbacks.

add_fact(subj, pred, obj)
remove_fact(subj, pred, obj)
query_kb(clauses, vars)   // first binding
query_kb_all(clauses, vars) // all bindings
register_event_handler(topic, cb)

Python · as2_python_api

KB Monitor Node

Event-driven mission layer. Declares RDF triple patterns; knowledge_core notifies on match. Mission scripts react without polling or direct call dependencies on behaviors.

Handler signature: handler(bindings, ctx) — plain Python function, no base class. ctx exposes query(), add_fact(), publish_mission_update(), pose, mission_status.

KB Monitor config (JSON — loaded at node startup)

{
  "kb_namespace": "kb",
  "handlers": [
    {
      "id": "assignment_done",
      "patterns": ["?drone is_assigned_to ?target"],
      "one_shot": false,
      "func": {
        "path": "/handlers.py",
        "func_name": "on_assignment"
      }
    }
  ]
}

Handler function (Python — invoked by knowledge_core on every pattern match)

def on_assignment(bindings, ctx):
    # bindings: list of dicts, one per matched triple set
    for b in bindings:
        msg = MissionUpdate()
        msg.drone_id = b['drone']
        msg.action   = MissionUpdate.RESUME
        msg.target   = b['target']
        ctx.publish_mission_update(msg)
    # ctx also exposes: ctx.query(), ctx.add_fact(), ctx.pose, ctx.mission_status

🏷️

Auction Behavior

Distributed task allocation via the auctions collective model

How it works

The auctioneer distributes inspection targets (items). All drones simultaneously compute distance-based costs (bids) and broadcast them via the CA Gateway. Each drone independently runs greedy_sequential — the same deterministic rule on the same bids produces the same assignment everywhere, with no central aggregator or extra communication rounds.

Auction message flow — interactive step-by-step

Press Next to walk through the auction protocol.

Plugin: greedy_sequential

Deterministic: assign each item to lowest-cost agent, break ties by namespace. Same rule + same bids = same assignment everywhere. No extra rounds.

Plugin: coordinate_item

Reads current pose from State Interface, computes Euclidean distance to a 3D target. Swappable without touching the behavior protocol.

KB Grounding

After convergence, asserts drone is_assigned_to target and auction_status done triples. KB Monitor triggers mission interpreter resumption for every drone.

🛡️

Collision Avoidance Behavior

Safe corridor arbitration via the consensus collective model

Core idea

Before any drone moves, it must acquire a distributed lock on its intended corridor. Peers grant the lock if their paths don't conflict. If two drones conflict simultaneously, the lexicographically smaller namespace wins. Consensus = receiving a grant from every known peer.

Pairwise path-lock state machine

Path-lock message flow — interactive step-by-step

Press Next to walk through the path-lock protocol.

Conflict detection: path_geometry::min_polyline_distance() checks all pairs of segments between two polylines. If result < safety_distance (default 1.5 m), paths conflict.

Three grant/defer cases

No conflict: grant immediately, store peer path for future checks.
Conflict while HOLDING: defer — push to deferred_ queue, flush when RELEASING.
Conflict while REQUESTING (simultaneous): lex tie-break — smaller namespace grants immediately, larger namespace defers.

bool should_grant = true;
if (state_ == HOLDING && conflicts(req.path, locked_path_))
    should_grant = false;
else if (state_ == REQUESTING && conflicts(req.path, locked_path_))
    should_grant = req.requester_id < own_id_;  // lex priority

if (should_grant) {
    send_grant(req.requester_id, req.req_id);
    peer_held_paths_[req.requester_id] = req.path;
} else {
    deferred_.push_back({req.requester_id, req.req_id, req.path});
}

🎬

Inspection Scenarios

How components combine to enable D7.1 use-case families

Normal Operation — Complete Inspection Loop

Mission Start

Script calls
drone.auction()

→

Bid Exchange

Distance costs broadcast via CA Gateway

→

Converge

greedy_sequential assigns targets; KB asserted

→

KB Reaction

Monitor detects is_assigned_to, resumes mission

→

Path Lock

CollisionAvoidance acquires corridor locks

→

Navigate

Drones fly; locks released on arrival

Normal Operation

Full Inspection Loop

Auction distributes PV panel targets
KB grounding resumes each drone's interpreter
Path-lock consensus ensures safe concurrent navigation

CA GatewayAuction BehaviorKB InterfaceCollision AvoidanceState Interface

UC1 — Robot Failure

Battery Decay & Replanning

State Interface caches battery; Power Management detects anomaly
KB fact drone0 battery_status critical triggers landing
KB Monitor removes drone from fleet
New auction reallocates uncovered targets

State InterfaceKB InterfaceKB MonitorAuction Behavior

UC2 — Emergency Landing

Safe Emergency Landing

Failing drone invokes CollisionAvoidance with emergency path
HOLDING peers grant immediately; REQUESTING peers apply lex tie-break
On landing, CAPathLockRelease unblocks all deferred peers

CA GatewayCollision Avoidancepairwise_path_lock

ID	Description	Implemented by	Status
IT-FR-002	Collaborative planning	Auction Behavior (greedy_sequential)	✔ Satisfied
IT-FR-003	System replanning on failure	Auction Behavior triggered by KB Monitor	✔ Satisfied
IT-FR-016	Failure resilience	KB Monitor + re-auction on UC1	✔ Satisfied
IT-FR-027	Information sharing between agents	KB Interface (shared RDF store)	✔ Satisfied
IT-FR-028	Swarm size awareness	CA Gateway peer discovery (dynamic)	✔ Satisfied
IT-FR-031	Trajectory collective-awareness	Collision Avoidance (path-lock broadcast)	✔ Satisfied
IT-FR-032	Security distance maintenance	Collision Avoidance (`safety_distance`)	✔ Satisfied
